L'écran IPS est une technologie basée sur TFT, et son écran TFT aussi.

1. il utilise la technologie de conversion horizontale pour rendre l'écran LCD plus réactif et stable.

2. IPS LCD a un grand angle de vue.

3. Peu importe l'angle, vous pouvez profiter de l'image idéale avec des couleurs vives, saturées et naturelles.

IPS signifie In-Plane Switching, c'est une technologie de panneau à cristaux liquides lancée en 2001, elle aussi appelée "Super TFT". L'écran LCD IPS est présenté pour une réponse rapide, un grand angle de vue, de vraies couleurs, un environnement, un toucher sans marque d'eau, un poids léger, etc.

Size(inch)	Resolution	Model No.	Outline Dimension(mm)	Active Area(mm)	View Angle	Interface	Luminance(nits)	Touch Screen	OP(℃)
0.96	80*160	Z10003	13.527.951.55	10.8*21.696	IPS	4-SPI	300	Support	-20℃~70℃
1.28	240*240	Z13006	35.6* 38.1*1.56	32.4*32.4	IPS	MCU-8	350	Support	-20℃~70℃
1.3	240*240	Z13001-P24	26.1729.221.53	23.40*23.40	IPS	MCU-8	500	Support	-20℃~70℃
1.3	240*240	Z13001	26.1729.221.53	23.40*23.40	IPS	4-SPI	500	Support	-20℃~70℃
1.3	240*240	Z13002	26.1729.221.53	23.40*23.40	IPS	4-SPI	500	Support	-20℃~70℃
1.3	240*240	Z13004	26.1729.221.5	23.40*23.40	IPS	SPI	450	Support	-20℃~70℃
1.3	360*360	Z13005	35.24 37.67 2.15	32.94*32.94	IPS	SPI	700	Support	-20℃~70℃
1.46	360*360	Z14601	39.340.961.6	32.94*32.94	IPS	SPI	300	Support	-20℃~70℃
1.47	172*320	Z147001	19.6536.761.56	17.65*32.83	IPS	SPI	350	Support	-20℃~70℃
1.54	240*240	Z15002	31.5233.721.94	27.72*27.72	IPS	MCU-8/ 16	350	Support	-20℃~70℃
1.5	320*320	Z15004	31.5233.721.9 (T)	27.744*27.744	IPS	MIPI	600	Support	-20℃~70℃
1.54	240*240	Z154001	31.5035.01.91	27.72*27.72	IPS	8 -MCU/4-SPI	300	Support	-20℃~70℃
1.6	400*400	Z16003	42.945.891.60	39.84*39.84	IPS	SPI	350	Support	-20℃~70℃
1.69	240*280	Z169001	30.0737.431.6	27.97*32.63	IPS	SPI	450	Support	-20℃~70℃
1.77	128*160	Z18001	34.0045.802.45	28.03*35.04	IPS	MCU-8		Support	-20℃~70℃
2.0	240*320	Z20001	37.6851.322.30	30.60*40.80	IPS	MCU-8/4-SPI		Support	-20℃~70℃
2. 1	480*480	Z21001	56.1859.712.3	53.28*53.28	IPS	SPI+RGB	350	Support	-20℃~70℃
2. 1	480*480	Z21002	56.1859.712.26	53.28*53.28	IPS	MIPI	380	Support	-20℃~70℃
2.4	240*320	Z24006	40.5257.002.15	36.72*48.76	IPS	MCU		Support	-20℃~70℃
2.4	240*320	Z24008	40.5257.002.15	36.72*48.76	IPS	MIPI		Support	-20℃~70℃
2.8	240*320	Z28001	47.4065.952.25	43.20*57.60	IPS	MCU		Support	-20℃~70℃
2.8	240*320	Z28005	5069.202.30	43.20*57.60	IPS	MCU/SPI	700	Support	-20℃~70℃
2.8	480*480	Z28007	73.0376.482.30	70.128*70.128	IPS	SPI+RGB	300	Support	-20℃~70℃
3.0	480*854	Z30010	42.7074.702.50	37.44*66.61	IPS	SPI+RGB	400	Support	-20℃~70℃
3.0	480*854	Z30032	42.7074.702.50	37.44*66.61	IPS	MIPI/SPI+RGB	500	Support	-20℃~70℃
3.0	480*854	Z30043	40.6474.681.74	37.44*66.61	IPS	MIPI	350	Support	-20℃~70℃
3.0	480*854	Z30052	42.7074.702.50	37.44*66.61	IPS	SPI+RGB	400	Support	-20℃~70℃
3.0	480*854	Z30054	40.6474.682.34	37.44*66.61	IPS	MIPI	550	Support	-20℃~70℃
3.0	480*854	Z30056	42.7074.702.50	37.44*66.61	IPS	MIPI		Support	-20℃~70℃
3.0	480*854	Z30060	42.7074.702.50	37.44*66.61	IPS	MIPI	400	Support	-20℃~70℃
3.0	480*854	Z30074	40.6474.681.74	37.44*66.61	IPS	MIPI	480	Support	-20℃~70℃
3.0	480*854	Z30078	42.7074.702.45	37.44*66.61	IPS	SPI+RGB	500	Support	-20℃~70℃
3.0	480*854	Z30079	42.7074.702.50	37.44*66.61	IPS	MIPI	380	Support	-20℃~70℃
3.0	480*854	Z30082	40.6474.681.74	37.44*66.61	IPS	MIPI	500	Support	-20℃~70℃
3.0	480*854	Z30083	40.6474.682.34	37.44*66.61	IPS	MIPI	500	Support	-20℃~70℃
3.4	480*480	Z34001	65.7269.642.45	60.48*60.48	IPS	SPI+RGB/MIPI	500	Support	-20℃~70℃
3.4	800*800	Z34005	94.9096.951.16	87.60*87.60	IPS	SPI+RGB	600	Support	-20℃~70℃
3.5	320*240	Z35008	76.7863.743.20	70.08*52.56	IPS	RGB		Support	-20℃~70℃
3.5	320*480	Z35013	53.7682.392.23	48.96*73.44	IPS	MIPI	330	Support	-20℃~70℃
3.5	320*480	Z35013-P12	53.7682.392.4	48.96*73.44	IPS	SPI	330	Support	-20℃~70℃
3.5	640*480	Z35101	76.8463.843.27	70.08*52.56	IPS	RGB	450	Support	-20℃~70℃
3.5	320*480	Z35018	53.7682.392.23	48.96*73.44	IPS	SPI	300	Support	-30℃~85℃
3.5	480*800	Z35030-P25	50.185.8 2.1	45.36*75.6	IPS	MIPI	300	Support	-20℃~70℃
3.5	480*800	Z35030-P40	50.185.82.1	45.36*75.6	IPS	SPI+RGB	300	Support	-20℃~70℃
3.71	240*960	Z37001	25.398.891.65	22.86*91.44	IPS	SPI+RGB	300	Support	-20℃~70℃
3.97	480*800	Z40032	55.4496.151.71	51.84*86.40	IPS	SPI+RGB		Support	-20℃~70℃
3.97	480*800	Z40035	55.4496.151.71	51.84*86.40	IPS	MIPI		Support	-20℃~70℃
3.95	720*720	Z40050	74.8378.982.14	71.93*71.93	IPS	MIPI		Support	-20℃~70℃
3.97	480*800	Z40045	55.4496.151.71	51.84*86.40	IPS	MIPI	320	Support	-20℃~70℃
3.97	480*800	Z40046	57.1496.852.15	51.84*86.40	IPS	MIPI	400	Support	-20℃~70℃
3.95	480*480	Z40048	74.8378.682.15	71.856*70.176	IPS	MIPI/SPI+RGB		Support	-20℃~70℃
4.00	720*720	Z40054	105.60109.872.22	101.52*101.52	IPS	MIPI	500	Support	-20℃~70℃
4.3	480*272	Z43014	105.4667.162.75	95.04*53.86	IPS	RGB	500	Support	-20℃~70℃
4.3	480*272	Z43016	105.4667.162.75	95.04*53.86	IPS	RGB	500	Support	-20℃~70℃
4.3	480*272	Z43017	105.4667.162.75	95.04*53.86	IPS	RGB	500	Support	-20℃~70℃
4.3	480*272	Z43018	105.4667.162.75	95.04*53.86	IPS	RGB	500	Support	-20℃~70℃
4.3	480*272	Z43021	105.4667.162.75	95.04*53.86	IPS	RGB	500	Support	-20℃~70℃
4.3	480*800	Z43027	60.46103.651.86	56.16*93.70	IPS	SPI+RGB/MIPI	500	Support	-20℃~70℃
4.3	480*272	HXH43029	105.4667.162.75	95.04*53.86	IPS	RGB	600	Support	-20℃~70℃
4.3	800*480	Z43080	105.4667.13.0	95.04*53.86	IPS	RGB	1000	Support	-20℃~70℃
4.5	480*854	Z45058	58.69107.482.03	55.44*98.64	IPS	MIPI		Support	-20℃~70℃
4.5	480*854	Z45059	58.75107.41.9	55.44*98.64	IPS	MIPI		Support	-20℃~70℃
5.0	480*854	Z49399	66.40120.052.25	61.63*109.65	IPS	SPI+RGB	530	Support	-20℃~70℃
5.0	480*854	Z49416	66.40120.052.25	61.63*109.65	IPS	MIPI	600	Support	-20℃~70℃
5.0	480*854	DM49417	66.3120.32.03	62.06*110.4	IPS	MIPI	400	Support	-20℃~70℃
5.0	720*1280	Z49420	65.89119.911.65	63.72*113.28	IPS	MIPI	450	Support	-20℃~70℃
5.0	720*1280	Z49421	67.56122.353.28	62.60*111.08	IPS	MIPI	450	Support	-20℃~70℃
5.0	1080*1080	Z50006	136.531132.21.98	127.008127.008	IPS	MIPI	500	Support	-20℃~70℃
5.0	800*480	Z50070	120.775.83.0	108*64.8	IPS	RGB	350	Support	-20℃~70℃
5.5	720*1280	Z55290	71.00130.201.67	68.04*120.96	IPS	MIPI	350	Support	-20℃~70℃
5.5	720*1280	Z55292	71.00130.201.67	68.04*120.96	IPS	MIPI	420	Support	-20℃~70℃
5.7	320*240	Z57003	12798.438.2	115.2*86.4	IPS	MIPI	1300	Support	-20℃~70℃
5.7	640*480	Z57011	12798.438.2	115.2*86.4	IPS	MIPI	1300	Support	-20℃~70℃
6.0	720*1480	Z60036	70.8145.5 2.25	66.744*137.196	IPS	MIPI	350	Support	-20℃~70℃
6.86	480*1280	Z686006	65.82171.792.60	60.22*160.59	IPS	MIPI	500	Support	-20℃~70℃
6.9	720*1440	Z69001	83.75169.372.35	78.02*156.04	IPS	MIPI	450	Support	-20℃~70℃
6.95	600*1024	CD0695025LCD	95163.22.6	89.28*152.37	IPS	MIPI	330	Support	-20℃~70℃
6.95	600*1024	CD0695039	95163.152.5	89.28*152.37	IPS	MIPI	400	Support	-20℃~70℃
7.0	600*1024	Z70001	95163.152.5	89.28*152.37	IPS	MIPI	500	Support	-20℃~70℃
7.0	720*1280	Z70010	91.44*165.91	86.94*154.56	IPS	MIPI		Support	-20℃~70℃
7.0	1024*600	Z70017	163.796.92.59	154.21*85.92	IPS	MIPI	500	Support	-20℃~70℃
7.0	600*1024	Z70027	95163.22.6	89.28*152.37	IPS	MIPI	400	Support	-20℃~70℃
7.0	1024*600	Z70048	163.7096.92.6	154.21*85.92	IPS	RGB		Support	-20℃~70℃
7.0	1024*600	Z70049	163.7096.92.6	154.21*85.92	IPS	MIPI		Support	-20℃~70℃
7.0	1024*600	Z70069	163.796.9 2.59	154.21*85.92	IPS	RGB	700	Support	-20℃~70℃
7.0	1024*600	Z70070	1611073.35	149.76*93.6	IPS	MIPI		Support	-20℃~70℃
6.95	600*1024	Z70072	94.90163.102.53	89.28*152.37	IPS	MIPI	350	Support	-10℃~50℃
7.0	1024*600	Z70078	163.796.92.55	154.21*85.92	IPS	MIPI	500	Support	-20℃~70℃
7.0	720*1280	Z70079	90.5163.82.65	87.264*155.136	IPS	MIPI		Support	-10℃~60℃
7.0	600*1024	HL070WSCAV019	94.94163.242.51	89.28*152.37	IPS	MIPI	350	Support	-20℃~70℃
7.0	720*1280	Z70085	91.44*165.91	86.94*154.56	IPS	MIPI	370	Support	-20℃~70℃
7.0	800*1280	Z70088	99.6560.852.40	94.20*150.72	IPS	MIPI	1000	Support	-30°C~85°C
7.0	1200*1920	Z70102	99.81161.66 2. 18	94.5*151.2	IPS	MIPI	1000	Support	-20℃~70℃
7.0	1024*600	Z70103	164.8699.963.6	154.21*85.92	IPS	RGB	1000	Support	-20℃~70℃
7.84	400*1280	Z784001	67.14205.124.50	59.40*190.08	IPS	MIPI		Support	-20℃~70℃
8.0	800*1280	Z80008-SPM288	114.60184.102.61	107.64*172.72	IPS	MIPI	380	Support	-20℃~70℃
8.0	800*1280	Z80019	114.66184.162.65	107.64*172.224	IPS	MIPI	580	Support	-20℃~70℃
8.0	1200*1920	Z80035-P39	122.44183.672.62	107.64*172.22	IPS	MIPI	800	Support	-20℃~70℃
8.0	1280*800	Z80036	181.85119.302.40	172.22*107.64	IPS	LVDS	350	Support	-20℃~70℃
8.0	1280*720	Z80051	192.80116.906.40	176.64*99.36	IPS	LVDS	800	Support	-20℃~70℃
8.8	480*1280	Z88001	64.10231.204.70	54.72*218.88	IPS	MIPI	550	Support	-20℃~70℃
8.9	800*1280	PJ8901B01	125.48202.90 2.6	119.28*190.85	IPS	MIPI	350	Support	-20℃~70℃
9.0	800*1280	Z90006	125.48202.902.60	119.28*190.85	IPS	MIPI	500	Support	-20℃~70℃
9.0	800*1280	Z90010	125.48202.902.60	119.28*190.85	IPS	MIPI	300	Support	-20℃~70℃
9.0	800*1280	Z90014-SPM308H	125.48202.902.6	119.28*190.85	IPS	MIPI	350	Support	-20℃~70℃
9.0	800*1280	Z90018	125.48202.902.55	119.28*190.84	IPS	MIPI	350	Support	-20℃~70℃
9.0	800*1280	Z90019	125.5202.942.6	119.28*190.84	IPS	MIPI	350	Support	-20℃~70℃
9.0	1024*600	Z90080	201.7126.55	196.906*114.158	IPS	LVDS	400	Support	-20℃~70℃
10. 1	1200*1920	Z101017	143.10228.602.6	135.36*216.58	IPS	MIPI	400	Support	-20℃~70℃
10. 1	800*1280	Z101020	143.1228.62.6	135.36*216.58	IPS	MIPI	300	Support	-20℃~70℃
10. 1	800*1280	Z101024	143.1228.62.6	135.36*216.58	IPS	MIPI	350	Support	-20℃~70℃
10. 1	800*1280	Z101027	143228.62.63	135.36*216.58	IPS	MIPI	350	Support	-20℃~70℃
10.36	1200*2000	Z101028	140.36234.631.9	135.36*225.60	IPS	MIPI	300	Support	-15℃~60℃
10. 1	1024*600	Z101060-P50	2351435.2	222.72*125.28	IPS	RGB	450	Support	-20℃~70℃
10. 1	1280*800	Z101080	229.45149.222.62	216.96*135.6	IPS	LVDS	350	Support	-20℃~70℃
10. 1	1920*1200	Z10100-P45	228.51494.55	216.81*135.5	IPS	LVDS	1000	Support	-20℃~70℃
11.6	1920*1080	Z116001	263.4167.25 2.6	256.32*144.18	IPS	LVDS		Support	-20℃~70℃
12.3	1920*720	Z123001	299.51235.92	292.032*109.512	IPS	LVDS	1300	Support	-20℃~70℃
12.3	1920*720	Z123003	321.6138.86.15	292.032*109.512	IPS	LVDS	1000	Support	-20℃~70℃
